Dragino D20-NB2 NB-IoT Waterproof /Outdoor Temperature Sensor (19000 mAh)

Name: Dragino D20-NB2 NB-IoT Waterproof /Outdoor Temperature Sensor (19000 mAh)
Brand: Dragino
SKU: D20-NB2-GE
Price: 60.95 EUR
Availability: InStock

€60.95

Tax excluded

NB-IoT Temperature Sensor for Internet of Things solution. Powered by 19000mAh Li-SOCI2 battery.

Quantity

Last items in stock

Security policy:

We protect your data with strict security measures to prevent unauthorized access.

Delivery policy:

Shipments in 2-7 business days depending on the courier selected during the purchase of the product.

Return policy

You can return your purchase within 14 days if the product and packaging are in perfect condition.

Description
Product Details

The Dragino D20-NB is a NB-IoT Temperature Sensor for Internet of Things solution. D20-NB will convert the Temperature reading to upload the sensor data send to IoT platform via NB-IoT network.

The temperature sensor used in D20-NB can measure -55°C ~ 125°C with accuracy ±0.5°C (max ±2.0 °C).

D20-NB supports temperature alarm feature, user can set temperature alarm for instant notice.

D20-NB supports diferent uplink methods including MQTT, MQTTs, UDP & TCP for diferent application requirement, and support uplinks to various IoT Servers.

D20-NB supports BLE confgure and OTA update which make user easy to use.

D20-NB is powered by 19000mAh Li-SOCI2 battery, it is designed for long-term use up to several years.

D20-NB has optional built-in SIM card and default IoT server connection version. Which makes it works with simple confguration.

Features:

    NB-IoT Bands:B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B25/B28/B66/B70/B85 @H-FDD
    Ultra Low Power Consumption
    1 x DS18B20 Temperature probe
    Measure range: -55°C ~ 125°C
    Temperature alarm
    IP66 Waterproof Enclosure
    Support BLE remote configure and update firmware
    Uplink on periodically
    Downlink to change configure
19000mAh Battery for long term use
    Nano SIM card slot for NB-IoT SIM

Specifications:

Common DC Characteristics :

    Supply Voltage: 2.5v ~ 3.6v
    Operating Temperature: -40 ~ 85°C

Temperature Sensor :

    Dallas DS18B20
    Range: -55 to + 125°C
    Accuracy ±0.5°C (max ±2.0 °C).

LoRa Spec :

NB-IoT Module: BC660K-GL

Support Bands:

    B1 @H-FDD: 2100MHz
    B2 @H-FDD: 1900MHz
    B3 @H-FDD: 1800MHz
    B4 @H-FDD: 2100MHz
    B5 @H-FDD: 860MHz
    B8 @H-FDD: 900MHz
    B12 @H-FDD: 720MHz
    B13 @H-FDD: 740MHz
    B17 @H-FDD: 730MHz
    B18 @H-FDD: 870MHz
    B19 @H-FDD: 870MHz
    B20 @H-FDD: 790MHz
    B25 @H-FDD: 1900MHz
    B28 @H-FDD: 750MHz
    B66 @H-FDD: 2000MHz
    B70 @H-FDD: 2000MHz
    B85 @H-FDD: 700MHz

Battery :

    Li/SOCI2 un-chargeable battery
    Capacity: 19000mAh
    Self-Discharge: <1% / Year @ 25°C
    Max continuously current: 130mA
    Max boost current: 2A, 1 second

Power Consumption：

    STOP Mode: 10uA @ 3.3v
    Max transmit power: 350mA@3.3v
